Understanding Kubernetes Networking: Services and Ingress
Mastering Kubernetes Networking: How Services and Ingress Facilitate Seamless Communication
Kubenatives Newsletter - Edition #3
🚀 Welcome to this edition of the Kubenatives Newsletter! Kubernetes networking is a critical component of how workloads communicate, whether within the cluster or externally.
In this edition, we will take a deep dive into Services and Ingress, two key networking resources that enable efficient and scalable communication.
🌐 1. Kubernetes Networking Overview
Before diving into Services and Ingress, it's important to understand the fundamentals of Kubernetes networking. Kubernetes networking is based on the following principles:
✅ Each Pod gets a unique IP address within the cluster.
✅ All Pods in a cluster can communicate with each other without NAT.
✅ IP-per-Pod model enables clear separation of traffic.
✅ Service abstraction provides stable networking endpoints.
Kubernetes does not provide traditional Layer 2 networking (like VLANs) but relies on Container Network Interface (CNI) plugins such as Calico, Flannel, or Cilium to manage networking.
📡 2. Kubernetes Services: Ensuring Stable Communication
🔹 What is a Service?
A Kubernetes Service is an abstraction that provides a stable way to access Pods. Since Pods are ephemeral and can be replaced, their IP addresses are not reliable. A Service ensures a persistent way to access a set of Pods.
🔹 Types of Services
1️⃣ ClusterIP (Default) - Exposes the service only within the cluster.
2️⃣ NodePort - Exposes the service externally on each node’s IP at a static port.
3️⃣ LoadBalancer - Provisions a cloud provider’s external load balancer.
4️⃣ ExternalName - Maps a service to an external DNS name.
🔹 How Services Enable Load Balancing
Kubernetes Services automatically distribute traffic across the available Pods based on labels and selectors, ensuring high availability and resilience.
apiVersion: v1
kind: Service
metadata:
name: my-service
spec:
selector:
app: my-app
ports:
- protocol: TCP
port: 80
targetPort: 8080
🌍 3. Kubernetes Ingress: Managing External Access
🔹 What is an Ingress?
An Ingress is a Kubernetes resource that manages external HTTP/S access to services inside the cluster. It provides routing rules, SSL termination, and virtual hosting capabilities.
🔹 How Ingress Works
Uses Ingress Controller (e.g., NGINX, Traefik, Kong) to process requests.
Routes traffic based on hostnames and paths.
Supports TLS termination for secure connections.
🔹 Ingress Example
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
name: my-ingress
spec:
rules:
- host: example.com
http:
paths:
- path: /
pathType: Prefix
backend:
service:
name: my-service
port:
number: 80
This configuration ensures traffic to example.com is routed to my-service inside the cluster.
🔄 4. Choosing Between Services and Ingress
Layer: Services operate at Layer 4 (TCP/UDP), while Ingress operates at Layer 7 (HTTP/HTTPS).
Load Balancing: Both provide load balancing, but Ingress relies on an Ingress Controller.
Path-Based Routing: Services do not support path-based routing, whereas Ingress allows routing based on hostnames and paths.
TLS Termination: Services do not natively support TLS termination, but Ingress provides this feature.
External Access: Services expose workloads externally using LoadBalancer or NodePort, whereas Ingress provides a more structured and efficient way to manage HTTP/S traffic.
Use services for internal communication and ingress to manage external HTTP/S traffic efficiently.
🎯 Conclusion
Understanding Services and Ingress is essential for building scalable and robust Kubernetes applications. While Services provide stable internal networking, Ingress helps manage external traffic efficiently. By leveraging these components, you can ensure seamless communication in Kubernetes clusters.
